B3951(JE40)

B3951(JE40)

间距(pitch):3.96mm(.156"

技术参数 SPECIFICATIONS

线数(Poles):2~15

适用线规(Applicable wires)::AWG18#~22#

温度范围(Temperature range) :-25℃~85℃

额定电压(Voltage rating):250V.Ac/Dc

额定电流(Current rating):5A AC,DC

接触电阻(Contact resistance):≤0.02Ω

绝缘电阻(lnsulation resistance):≥1000MΩ

耐压(Withstand voltage):1500V.Ac/1min

材料(Material):

胶壳(Housing):尼龙(Nylon)UL94V-2(0)

端子(Terminal:磷青铜(Phos.bronze Tin/plated
